ESM1v N1 API ESM1v N2 API ESM1v N3 API
Learn how to perform an in-silico deep mutational scan with three of the five ESM-1v models. This method is suitable for finding the most likely mutations 1x - 3x distance from a parent sequence. For going beyond 3x mutations, other methods such as inverse-folding or finetuning a generative model are more appropriate and less time-bound.
While ESM2 has similar performance to ESM-1v, the latter is still a great option for performing an in silico deep mutational scan. ESM-1v is a collection of five models, trained on sequences from UniRef, each with different seeds. Ensembling these five models' scores can produce better results than a single ESM-1v model, for such broad topics like identifying stabilizing mutations.
Since these models were only trained on functional molecules, they are capable of assessing whether a new molecule might also be functional, or whether it has a disastrous mutation.
Imagine only learning and speaking English your whole life - could you identify whether a new English word is English? Probably. What about whether a Korean word is Korean? Or whether a French word is French? You might not be able to identify a Korean word as specifically Korean since you were only exposed to English; but you can tell that some foreign words are at least not-English. The idea is similar with this zero-shot model, ESM-1v: how likely is a sequence functional, since the model was only exposed to functional sequences.
In order to use the BioLM API, you need to have a token. You can get one from the User API Tokens page.
Paste the API token you generated in the cell below, as the value of the variable BIOLMAI_TOKEN.
BIOLMAI_TOKEN
BIOLMAI_TOKEN = " " # YOUR TOKEN GOES HERE!!!
We do this by masking each position and requesting the scores for each residue at that position. For a sequence of even a couple hundred residues, this is thousands of predictions from each of the 5 GPU-based models. BioLM has APIs to get these results at scale much faster than it would take to spin up these models on multiple GPUs alone.
# Install or import `requests` package try: # Install packages to make API requests in JLite import micropip await micropip.install('requests') await micropip.install('pyodide-http') # Patch requests for in-browser support import pyodide_http pyodide_http.patch_all() await micropip.install('pandas') await micropip.install('matplotlib') await micropip.install('seaborn') except ModuleNotFoundError: pass # Won't be using micropip outside of JLite import requests
# Let's use the sequence from the paper # https://www.biorxiv.org/content/10.1101/2021.07.09.450648v2.full.pdf WILDTYPE = "ASKGEELFTGVVPILVELDGDVNGHKFSVSGEGEGDATYGKLTLKFICTTGKLPVPWPTLVTTFSYGVQCFSRYPDHMKRHDFFKSAMPEGYVQERTIFFKDDGNYKTRAEVKFEGDTLVNRIELKGIDFKEDGNILGHKLEYNYNSHNVYIMADKQKNGIKVNFKIRHNIEDGSVQLADHYQQNTPIGDGPVLLPDNHYLSTQSALSKDPNEKRDHMVLLEFVTAAGITHGMDELYK" print("Sequence length: {}".format(len(WILDTYPE)))
Sequence length: 238
We can copy working Python code for making a request to BioLM.ai's ESM-1v API:
def esm1v_pred(seq, model_num=1): """Get un-masking predictions from any of the 5 ESM-1v models via REST API. From API docs: https://api.biolm.ai/#54d3367a-b5d1-4f18-aa44-23ae3914a446 """ SLUG = f'esm1v-n{model_num}' url = f'https://biolm.ai/api/v2/{SLUG}/predict/' assert '<mask>' in seq assert 5 >= model_num >= 1 data = { "items": [ { "sequence": seq } ] } headers = { "Content-Type": "application/json", "Authorization": f"Token {BIOLMAI_TOKEN.strip()}", } # Make the request! response = requests.post( url=url, headers=headers, json=data, ) return response
Now test our function on the first residue and first model.
result = esm1v_pred('<mask>' + WILDTYPE[1:], model_num=1) # First ESM-1v model pred = result.json() pred
{'results': [[{'token': 20, 'token_str': 'M', 'score': 0.90923011302948, 'sequence': 'M S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 4, 'token_str': 'L', 'score': 0.00893514882773161, 'sequence': 'L S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 7, 'token_str': 'V', 'score': 0.007254290860146284, 'sequence': 'V S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 6, 'token_str': 'G', 'score': 0.0071580721996724606, 'sequence': 'G S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 12, 'token_str': 'I', 'score': 0.006673584226518869, 'sequence': 'I S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 8, 'token_str': 'S', 'score': 0.00605518976226449, 'sequence': 'S S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 15, 'token_str': 'K', 'score': 0.005998397711664438, 'sequence': 'K S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 11, 'token_str': 'T', 'score': 0.00533581618219614, 'sequence': 'T S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 5, 'token_str': 'A', 'score': 0.00529194762930274, 'sequence': 'A S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 18, 'token_str': 'F', 'score': 0.005088561214506626, 'sequence': 'F S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 13, 'token_str': 'D', 'score': 0.005014363676309586, 'sequence': 'D S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 9, 'token_str': 'E', 'score': 0.004764892160892487, 'sequence': 'E S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 17, 'token_str': 'N', 'score': 0.004458808805793524, 'sequence': 'N S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 19, 'token_str': 'Y', 'score': 0.004456241149455309, 'sequence': 'Y S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 14, 'token_str': 'P', 'score': 0.0035370574332773685, 'sequence': 'P S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 10, 'token_str': 'R', 'score': 0.0032345277722924948, 'sequence': 'R S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 16, 'token_str': 'Q', 'score': 0.0027003914583474398, 'sequence': 'Q S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 21, 'token_str': 'H', 'score': 0.0017103749560192227, 'sequence': 'H S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 22, 'token_str': 'W', 'score': 0.0015011748764663935, 'sequence': 'W S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}, {'token': 23, 'token_str': 'C', 'score': 0.0014352151192724705, 'sequence': 'C S K G E E L F T G V V P I L V E L D G D V N G H K F S V S G E G E G D A T Y G K L T L K F I C T T G K L P V P W P T L V T T F S Y G V Q C F S R Y P D H M K R H D F F K S A M P E G Y V Q E R T I F F K D D G N Y K T R A E V K F E G D T L V N R I E L K G I D F K E D G N I L G H K L E Y N Y N S H N V Y I M A D K Q K N G I K V N F K I R H N I E D G S V Q L A D H Y Q Q N T P I G D G P V L L P D N H Y L S T Q S A L S K D P N E K R D H M V L L E F V T A A G I T H G M D E L Y K'}]]}
from IPython.display import JSON JSON(pred)
<IPython.core.display.JSON object>
We can see that "M", or Methionine is the most likely starting AA. Methionine is a common starting AA amongst many organisms.
"M"
Next, We can get predictions from the other ESM-1v models, then ensemble the likelihood scores for best results.
res = esm1v_pred('<mask>' + WILDTYPE[1:], model_num=2) # Second ESM-1v model pred = res.json() JSON(pred)
You can observe the probabilities for each token (amino acid residue) differing between the two models.
Loading the data into a DF is simple.
import pandas as pd
pd.DataFrame.from_dict(pred['results'][0], orient='columns')
Let's scan the whole sequence now, using several of the five ESM-1v models. This should be fairly fast sequentially. Let's simply loop through each model and position. For a final workflow, we would want to average predictions from all five models (the ESM-1v all endpoint does this directly), but for the sake of speed, we'll only use three here.
import copy results = [] def f(idx, seq, mdl): if idx % 20 == 0: print("Submitting twenty positions from {}/{} with ESM-1v Model {}".format(idx, len(seq), mdl)) # Mask that position seq_masked = list(copy.copy(seq)) seq_masked[idx] = '<mask>' seq_masked = ''.join(seq_masked) r = esm1v_pred(seq_masked, model_num=mdl) pred = r.json() # Request the probabilities of each AA at that mask r_df = pd.DataFrame.from_dict(pred['results'][0], orient='columns') r_df['model_num'] = mdl r_df['mask_pos'] = idx return r_df # We'll just query the first 3 models for now, that's enough for mdl in range(1, 4): ops = [f(i, WILDTYPE, mdl) for i in range(len(WILDTYPE))] results = ops
Submitting twenty positions from 0/238 with ESM-1v Model 1 Submitting twenty positions from 20/238 with ESM-1v Model 1 Submitting twenty positions from 40/238 with ESM-1v Model 1 Submitting twenty positions from 60/238 with ESM-1v Model 1 Submitting twenty positions from 80/238 with ESM-1v Model 1 Submitting twenty positions from 100/238 with ESM-1v Model 1 Submitting twenty positions from 120/238 with ESM-1v Model 1 Submitting twenty positions from 140/238 with ESM-1v Model 1 Submitting twenty positions from 160/238 with ESM-1v Model 1 Submitting twenty positions from 180/238 with ESM-1v Model 1 Submitting twenty positions from 200/238 with ESM-1v Model 1 Submitting twenty positions from 220/238 with ESM-1v Model 1 Submitting twenty positions from 0/238 with ESM-1v Model 2 Submitting twenty positions from 20/238 with ESM-1v Model 2 Submitting twenty positions from 40/238 with ESM-1v Model 2 Submitting twenty positions from 60/238 with ESM-1v Model 2 Submitting twenty positions from 80/238 with ESM-1v Model 2 Submitting twenty positions from 100/238 with ESM-1v Model 2 Submitting twenty positions from 120/238 with ESM-1v Model 2 Submitting twenty positions from 140/238 with ESM-1v Model 2 Submitting twenty positions from 160/238 with ESM-1v Model 2 Submitting twenty positions from 180/238 with ESM-1v Model 2 Submitting twenty positions from 200/238 with ESM-1v Model 2 Submitting twenty positions from 220/238 with ESM-1v Model 2 Submitting twenty positions from 0/238 with ESM-1v Model 3 Submitting twenty positions from 20/238 with ESM-1v Model 3 Submitting twenty positions from 40/238 with ESM-1v Model 3 Submitting twenty positions from 60/238 with ESM-1v Model 3 Submitting twenty positions from 80/238 with ESM-1v Model 3 Submitting twenty positions from 100/238 with ESM-1v Model 3 Submitting twenty positions from 120/238 with ESM-1v Model 3 Submitting twenty positions from 140/238 with ESM-1v Model 3 Submitting twenty positions from 160/238 with ESM-1v Model 3 Submitting twenty positions from 180/238 with ESM-1v Model 3 Submitting twenty positions from 200/238 with ESM-1v Model 3 Submitting twenty positions from 220/238 with ESM-1v Model 3
results[0] # Look at the first result DF we made
Concatenate the resulting DFs together, horizontally.
results_df = pd.concat(results, axis=0) results_df.shape
(4760, 6)
results_df.sample(5) # Sample some of the results to get a preview
Let's quickly fill in the WT character for each row so we can plot the results.
results_df['wt_token_str'] = results_df.mask_pos.apply(lambda x: WILDTYPE[x]) results_df.sample(3)
Lastly, make a DF displaying a heatmap of the most probable stabilizing variants from the above in silico deep mutational scan.
heatmap_df = [] # Each row represents the full sequence, with a single token_str at each position for residue in results_df.token_str.drop_duplicates().to_list(): tmp_row = [] for pos in range(len(WILDTYPE)): token_position_score = results_df.query('token_str == @residue & mask_pos == @pos').score.iloc[0] tmp_row.append(token_position_score) heatmap_df.append(tmp_row)
heatmap_df = pd.DataFrame(heatmap_df) heatmap_df.shape
(20, 238)
heatmap_df.head(1).iloc[0][0]
0.8598923683166504
from matplotlib import pyplot as plt import seaborn as sns fig = plt.figure(figsize=[15, 4]) ax = sns.heatmap(heatmap_df) _ = ax.set_xticklabels(list(WILDTYPE)[::int(len(WILDTYPE)/50)]) _ = ax.set_yticklabels(results_df.token_str.drop_duplicates()) _ = ax.set(xlabel='Wildtype Residue', ylabel='Variant')
This is a quick depiciton of the results. What you want to look for in the DF is mutations where the score is greater than the score of the wild-type residue at the same location. These can be extracted with some quick slicing of results_df, which we'll leave up to you to explore. There appear to be several mutations with greater likelihood that the wild-type sequence.
results_df
Check out additional tutorials at jupyter.biolm.ai, or head over to our BioLM Documentation to explore additional models and functionality.
